Sistema anti-collisione CAS-M LIGHT 1MBaud
Use Mouse Wheel to Zoom In/Out
| Item code: | F02UV02220 |
|---|---|
| Marca: |  |
| Codice Produttore: | F 02U V02 220-01 |
| Paese d'origine: | Germania |
| Codice doganale :: | 85261000 |
| Documenti: | |
| Weight: | 0,199 Kg |
Services
PrintDescription
The collision avoidance system CAS-M light helps the driver to focus on the track and warns him if a car is approaching from behind. The system provides information about relative speed and distance of the closest vehicle on the CAN bus. An additional display with CAN bus interface is required (e.g. DDU 9).The information is based on a Bosch radar sensor which contains a FMCW radar transceiver operating in the globally harmonized frequency range of 76.0 - 77.0 GHz. Targets in front of the sensor are reflecting the radar signal and the relative speed and distance is determined via Doppler-effect and beat frequency.
The benefit is even more increased during darkness or in bad weather conditions. The system interface is very intuitive and adaptable to the drivers liking.
Features
| Temperatura Operativa: | -40 a 85°C |
|---|---|
| Range (m): | 150 |
| Interfaccia: | CAN |
| CAN rate: | 500 kbaud oppure 1 Mbaud |
| CAN update rate: | 50 Hz |
| Peso (g): | 199 |
| Dimensioni (mm): | 60 a 70 x 32 |
| Alimentazione: | 6.5 a 18 V |
